RUTXR1 Router

1,776.00 zł

Enterprise Rack-Mountable SFP/LTE Router
Gigabit ETH: 5 x Gigabit Ethernet ports
Dual SIM: with auto failover, backup WAN and other switching scenarios
SFP: SFP port for long-range Fiber-optic communication
RMS: compatible with Teltonika Remote Management System
WIFI: Wave-2 802.11ac Dual Band WIFI
4G LTE Cat 6: cellular speeds up to 300Mbps with Carrier Aggregation

The given price is suggested manufacturer′s retail price excluding tax. Send inquiry for the best offer.

RUTXR1 is Teltonika first-ever rack-mounted LTE Cat6 router with redundant power supplies and WAN interfaces, which can be conveniently placed in a server cabinet. It is equipped with dual SIM, USB, and Wave-2 802.11ac Dual Band WIFI. But what makes this product stand out from the rest of Teltonika products are the SFP WAN and dedicated console ports. The unique feature set of this product allows using it as a primary product in a small or home office with LTE backup capabilities, powerful WiFi, and no need for an additional SFP to Ethernet converter. This feature-rich device is powered by RutOS and is a perfect choice, where a speedy and ultra-reliable connection is required! The device offers a wide range of supported power supply voltages (9-30 V) and operating temperatures (-40°C ~ +75°C).

Standard package contains
- RUTXR1 Router
- 18W PSU
- 2 x LTE antennas (magnetic mount, SMA male, 3 m cable)
- 2 x WiFi antennas (magnetic mount, RP-SMA male, 1.5 m cable)
- Rack - mounting kit
- 4 x Standing pads
- 8 x Screws
- SIM Adapter kit
- Ethernet cable (1.5 m)
- QSG (Quick Start Guide)
- RMS Flyer
- Packaging box

Full technical specification is available in Attachments.

Data sheet

Connectivity: 3G
4G/LTE Cat 6
WiFi standard: IEEE 802.11b/g/n/ac Wave 2
Ethernet ports: 5
Ethernet speed: 10/100/1000 Mbps
VPN: IPsec
OpenVPN
WireGuard
Operating system: RutOS (OpenWrt based Linux OS)
Operating voltage: 9-50 VDC
Power consumption Max: 18 W
USB ports: 1
SIM slots: 2
Serial ports: RS232
Dimensions: 272 x 42,6 x 122,6 mm
Weight: 1050 g
Mounting options: flat surface
rack
Operating temperature: -40°C ~ +75°C

Download

Datasheet RUTXR1

Download (1.21MB)

Flyer RUTXR1

Download (1.71MB)

Quick Start Guide RUTXR1

Download (253.22KB)
